Hydraulic Power Units, Size 2
delivery time
upon request
Are you ready for fast, simple, and efficient operating and testing of your aircraft hydraulic systems? Our Hydraulic Power Units are the answer to your needs. These units utilize state-of-the-art technology to offer more flow, more power, and less noise all at a competitive price.
Our size 2 HPU features an easily drainable 20-gallon (75 liter) fluid reservoir (versus the larger 60-gallon [227 liter] reservoir of the size 3).
Our HPUs are fitted with a modern digital display accompanied by an easy-to-use, software-driven operator interface. The included software allows for quick and easy access to settings, aircraft presets, calibration schedules, and more.
Our engineers developed these industry changing units with invaluable input from MROs and certified AMTs from around the world. Our HPUs offer advanced aircraft safety features, as well as electrical soft start that extends motor life by saving your motor from unnecessary wear and tear.
Are you ready for fast, simple, and efficient operating and testing of your aircraft hydraulic systems? AERO Specialties Hydraulic Power Units are the answer to your needs. These units utilize state-of-the-art technology to offer more flow, more power, and less noise all at a competitive price.
size 2 HPU features an easily drainable 20-gallon (75 liter) fluid reservoir (versus the larger 60-gallon [227 liter] reservoir of the size 3).
HPUs are fitted with a modern digital display accompanied by an easy-to-use, software-driven operator interface. The included software allows for quick and easy access to settings, aircraft presets, calibration schedules, and more.
Our engineers developed these industry changing units with invaluable input from MROs and certified AMTs from around the world. Our HPUs offer advanced aircraft safety features, as well as electrical soft start that extends motor life by saving your motor from unnecessary wear and tear.
Push Button Digital Screen
- Main dashboard displays live flow rate, pressure, fluid temperature, proper fluid level and the condition of both filters with an intuitive layout
- Three programmable setpoints for flow and pressure
- Available in French, German, English or Spanish in either metric or imperial units
- Maintenance dashboard allows quick input of the date/time, operator and aircraft tail numbers and tracks filter replacement and gauge calibration
- Easily navigated using backlit pushbuttons and rocker button
- Data logging generates useful reports for each individual test performed with a time stamped data file of all pressure, flow and temperatures
- Each file can be saved to a thumb drive and identified by the aircraft tail number
Standard Features - 3-micron synthetic pressure filter
- 5-micron, high dirt holding capacity return filter
- Visual and electronic filter clogging indicators
- Automatic high fluid temperature shutoff
- Visual reservoir sight glass
- Automatic high/low level reservoir monitoring with automatic shutoff
- 50 ft. (15.2 m) power cord, cables are pig-tailed and plug-ready (no plug included) – 2AWG 4 Conductor (25mm^2 EU)
- 25 ft. (7.6 m) supply and return hoses
- 5,000psi (345 bar) dual scale analog gauge
- Low noise, (<74dBa) Quieter than a shop vacuum
- Easy to access fluid sample port
- Fluid sampling valve meets ANSI T2.24.1-1991
- Easily drainable 20-gal (75 l) reservoir
- Ergonomically designed for easy maneuverability and low clearance in tight hangers
- stainless-steel skins
Locking hinged access doors and fully removable top for maintenance access
Full true drip pan with drain plug
Leak preventing hose hangers
Electric soft start
Super bright green running light
Super bright red warning/error light
Voltage Monitor
CE Compliant
